As-built set
From $1,875
Field-verified measurements turned into a clean, dimensioned existing-conditions drawing.
- On-site field measure
- Floor plans + elevations
- DWG + plotted PDF
CAD & engineering drafting · Hermosa Beach
Stamp-ready drawing sets your plan checker signs off the first time.
We convert redlines, field measurements, and design intent into coordinated, construction-ready CAD — permit drawings, structural detail sheets, and as-built documentation. One fixed fee per set, scoped before the first line is drawn.
Drafting for South Bay general contractors, structural engineers, and residential architects — DWG deliverables layered to NCS/AIA standards, plotted to scale.
Dd
Scale 1:50
How we engage
“Every set we deliver has a fixed fee, a named deliverable list, and two revision rounds baked in — agreed in writing before a single line hits the sheet.”
No hourly surprise, no scope creep. You get a drawing package priced to the work, not the clock — and native files you actually own.
- FeeFixed per project, locked at kickoffChange-of-scope quoted separately before it starts
- RevisionsTwo full redline rounds includedAdditional rounds billed at a flat per-sheet rate
- FilesNative .DWG + flattened PDFIFC / 3D model export on structural packages
- StandardsLayered to NCS / AIA CAD conventionsImperial dimensioning, title block matched to your firm
- Turnaround10–14 business days, typical setRush scheduling available — flagged at the scoping call
Rate card · billed per project
Four ways to put Daedalus Draft on your drawing set
Starting figures below cover a typical single-structure scope. Final fee is fixed at the scoping call once sheet count and detail depth are set.
Permit drawing set
From $3,450
A plan-check-ready package — the sheets your jurisdiction needs to issue the permit.
- Full dimensioned plans
- Code + sheet-index setup
- Two revision rounds
Structural details
From $4,650
Connection details, sections, and schedules coordinated to the engineer's calcs.
- Detail + section sheets
- Rebar / framing schedules
- IFC export included
Construction docs
From $8,900
The complete coordinated CD package, cover to detail — bespoke to the project.
- Architectural + structural
- Full coordination pass
- Priced after scoping
Before you send a project
Straight answers for contractors and architects
Intake
What do I need to send to start?
Whatever you have: a PDF markup, a hand sketch, a prior DWG, or just site photos and rough dimensions. For as-builts, nothing — we field-measure. We'll tell you exactly what's missing at the scoping call before any fee is set.
Standards
Imperial or metric, and which CAD standard?
Imperial dimensioning by default, metric on request. Layers follow the U.S. National CAD Standard / AIA conventions, and we'll match your firm's title block, line weights, and plot style so the set drops into your workflow.
Can you draft from a PDF or hand sketch?
Sources
Routinely. We rebuild scanned or flattened PDFs into clean, editable CAD geometry — not a traced image. Hand sketches get redrawn to scale with proper dimensioning and callouts.
Revisions
What if the plan checker comes back with corrections?
Comment responses on a permit set are expected — your package includes two full revision rounds covering standard plan-check corrections. If a correction requires a genuine scope change, we quote that separately before touching it.
Engineering
Do you stamp or do the calcs?
We are a drafting studio — we produce the drawings. Structural calcs and the professional stamp come from your licensed engineer; we coordinate our detail sheets directly to their calc package so everything lines up.
Ownership
Who owns the files?
You do, on delivery. You get the native .DWG plus plotted PDFs — no proprietary formats, no locked files. Edit, reissue, and archive them however your firm needs to.
From sketch to sheet set
The drafting path, start to delivery
-
01
Intake & redline review
We read your markups, prior drawings, and site photos, then flag gaps on a short scoping call. For existing structures, we book a field-measure visit and capture measurements on site.
-
02
Base model & coordination
Geometry is rebuilt clean in CAD — plans, elevations, sections — layered to standard and coordinated against the engineer's calcs where structure is involved.
-
03
Detailing & callouts
Connection details, schedules, dimensions, and sheet references go in. Title block, sheet index, and notes are set up to match your firm's conventions.
-
04
QA & plot-ready delivery
Every sheet is checked against a drafting QA list, then you receive native .DWG and plotted PDFs. Two revision rounds follow your redlines before the set is final.
Studio note
“A drawing set is a tool, not a deliverable to admire. If a framer, an inspector, or the next CAD tech can read it fast and build from it without calling you — it's right. That's the only test we grade our sheets against.”
— Daedalus Draft · 2601 Hermosa Ave, Hermosa Beach
Book a scoping call
Five steps between your sketch and a stamp-ready set.
1
Call
15-minute scope
2
Scope
Sheet list agreed
3
Proposal
Fixed fee in writing
4
Draft
Build + coordinate
5
Delivery
DWG + PDF
Tell us about the project
Send the scope — a line about what you're building and what you already have. We reply with next steps, usually within one business day.
Studio
2601 Hermosa Ave
Hermosa Beach, CA 90254
Invoiced per project · pay by card or ACH
